Section 2: General operation Series 2280 Precision DC Power Supply Reference Manual
2-26 077085503 / March 2019
Other system settings
Turn the instrument key-click sound on or off from this menu.
You can set the front-panel display to dim after a period of time, or
you can set it so that it will never dim.
You can adjust the brightness of the front-panel display. Selecting
this setting opens a sliding adjustment scale that adjusts the
brightness as a percent of total brightness.
Set the instrument month, day, year, and time from this menu.
Turn the error beeper on or off.
Change the remote connection or calibration passwords. You need
the remote connection password to open the LXI virtual front panel
and send SCPI commands. You need the calibration password
before you can calibrate the Series 2280.
Selecting this option resets many of the instrument commands to
their default values. For more information about what commands get
reset, see Reset default values (on page 2-88).
Selecting this option reverts the passwords to their default values.
System Event Log menu
The System Event Log menu allows you to view, save, and clear the event log. The event log entries
are error messages, which may indicate that a command was sent incorrectly.
Saves the event log to a .csv file on the USB flash drive. The file name is
eventlog.csv.
Clears all entries from the event log.
