Keithley 2600B

Series 2600B
System SourceMeter® Instrument Reference Manual Section 7:
TSP command reference
2600BS-901-01 Rev. C / August 2016 7-313
A set bit value indicates that the specified trigger blender generated an action overrun.
For information about .condition, .enable, .event, .ntr, and .ptr registers, refer to
Status register set
contents (on page E-1) and Enable and transition registers (on page E-19). The individual bits of this
register are defined in the following table.
Bit Value Description
B0
Not used
Not applicable
B1
status.operation.instrument.trigger_blender.trigger_overrun.BLND1
Bit B1 decimal
value: 2
B2
status.operation.instrument.trigger_blender.trigger_overrun.BLND2
Bit B2 decimal
value: 4
B3
status.operation.instrument.trigger_blender.trigger_overrun.BLND3
Bit B3 decimal
value: 8
B4
status.operation.instrument.trigger_blender.trigger_overrun.BLND4
Bit B4 decimal
value: 16
B5
status.operation.instrument.trigger_blender.trigger_overrun.BLND5
Bit B5 decimal
value: 32
B6
status.operation.instrument.trigger_blender.trigger_overrun.BLND6
Bit B6 decimal
value: 64
B7-B15 Not used Not applicable
As an example, to set bit B1 of the operation status trigger blender overrun enable register, set
status.operation.instrument.trigger_blender.trigger_overrun.enable =
status.operation.instrument.trigger_blender.trigger_overrun.BLND1.
In addition to the above constants, operationRegister can be set to the numeric equivalent of the
bit to set. To set more than one bit of the register, set operationRegister to the sum of their
decimal weights. For example, to set bits B1 and B4, set operationRegister to 18 (which is the
sum of 2 + 16).
Bit
B7
B6
B5
B4
B3
B2
B1
B0
Binary value
0/1
0/1
0/1
0/1
0/1
0/1
0/1
0/1
Decimal
128
64
32
16
8
4
2
1
Weights
(2
7
) (2
6
) (2
5
) (2
4
) (2
3
) (2
2
) (2
1
) (2
0
)
Bit
B15
B14
B13
B12
B11
B10
B9
B8
Binary value
0/1
0/1
0/1
0/1
0/1
0/1
0/1
0/1
Decimal
32,768
16,384
8,192
4,096
2,048
1,024
512
256
Weights
(2
15
) (2
14
) (2
13
) (2
12
) (2
11
) (2
10
) (2
9
) (2
8
)
Example
status.operation.instrument.trigger_blender.trigger_overrun.enable
= status.operation.instrument.trigger_blender.trigger_overrun.BLND1
Uses a constant to set the bit for blender 1 of the operation status trigger blender overrun enable
register.
Also see
Operation Status Registers (on page E-9)
status.operation.instrument.trigger_blender.* (on page 7-310)
