Series 2600B

System SourceMeter® Instrument Reference Manual Appendix E:

Status model

2600BS-901-01 Rev. C / August 2016 E-27

Status configuration (enable) commands

The following commands (sent from the master node) enable the appropriate register bits for the

above example:

Node 15 status registers: The following commands enable the current limit events for SMU A and B of

node 15:

node[15].status.measurement.current_limit.enable = 6

node[15].status.measurement.enable = 2

node[15].status.node_enable = 1

The affected status registers for the above commands are indicated by labels A, B and C (see

following figure).

Master node system summary registers: The following commands enable the required system

summary bits for node 15:

status.system2.enable = 2

status.system.enable = 1

The affected system summary registers for the above commands are indicated by labels D and E

(see following figure).

Master node service request: The following command enables the service request for the

measurement event:

status.request_enable = 1
