Keithley 6517B Reference Manual

Section 14: SCPI command reference Model 6517B Electrometer Reference Manual
14-112 6517B-901-01 Rev. C / August 2015
Positive transition effect on operation event register
Operation event Positive transition effect on operation event register
Calibrating Sets B0 at the start of calibration
Trigger layer Sets B5 when waiting in the trigger layer
Arm layer Sets B6 when waiting in an arm layer
Calculating Sets B9 when a reading is being calculated
Idle Sets B10 when entering the idle state
Sequence test running Sets B11 when a sequence test is running
Figure 130: Operation transition filter

Keithley 6517B Specifications

General

Input Impedance	>200 TΩ
Electrometer Type	Electrometer/High Resistance Meter
Current Measurement Range	20 fA to 20 mA
Display	Vacuum Fluorescent Display
Communication Interfaces	IEEE-488 (GPIB), RS-232
Power Supply	100 V / 120 V / 220 V / 240 V; 50 Hz / 60 Hz
Resistance Measurement Range	Up to 200 TΩ
