4-4 Keysight E5260/E5270 User’s Guide, Edition 6
Front Panel Reference
Display and Front Panel Keys
The display area consists of the following sub areas that have the meanings
described below.
• In normal operation, or when changing source output or compliance value:
• When changing measurement setup or source setup:
A Channel status T, C, V, X, or blank. See “Channel Status Area”
on page 4-6.
B Shift key status on (triangle mark) or off (blank). The
Shift
key
toggles the mark. While the mark appears, you can use the sub
key function instead of the original key function.
Setup Data 1, 2 Source output setting, source compliance setting, measurement
range setting, or error code. See “Setup Data Area” on page 4-7.
Meas Data 1, 2 Measured value, calculated power value, or calculated
resistance value. See “Measurement Data Area” on page 4-8.
Status Data Status information, measurement channel number, and source
channel number. See “Status Data Area” on page 4-9.
Change Setup Displays a setup menu or a setup message when you change any
setup. For details, see “Front Panel Key Details” on page 4-10
and “Setup Menus” on page 4-18.
A Meas Data 1 Meas Data 2 Setup Data 1 B
Status Data Setup Data 2
A Meas Data 1 Meas Data 2 Setup Data 1 B
Change Setup
