Keysight E5260/E5270 User’s Guide, Edition 6 5-3
Front Panel Operations
Available Functions
Available Functions
Table 5-1 lists the typical functions of the Keysight E5260/E5270.
Table 5-1 Typical Functions
Function
Operating Condition/Mode
Local Remote
To use multiple source channels Available Available
To use multiple measurement channels Not available Available
To apply DC voltage or DC current Available Available
To apply DC voltage and measure DC current Available Available
To apply DC current and measure DC voltage Available Available
To apply DC voltage and measure DC voltage Available Available
To apply DC current and measure DC current Available Available
To display measurement, source, status data Available
Available
a
a. In the remote mode and the default setting, only a part of the status
information is displayed. See “Status Data Area” on page 4-9.
To calculate power and display the value Available Not available
To calculate resistance and display the value Available Not available
To set GPIB Address Available Not available
To set power line frequency Available Not available
To execute self-test Available Available
To execute self-calibration Available Available
To execute diagnostics Available Available
To use trigger input/output Not available Available
To use digital interface Not available Available
