Keysight E5260/E5270 User’s Guide, Edition 6 4-9
Front Panel Reference
Display and Front Panel Keys
Status Data Area
The Status data area shows the following statuses.
NOTE In the remote mode and the default setting, the statuses of Output, Repeat, M-ch,
and S-ch are not displayed. To display all information, set the RMT_DSPL function
ON. Refer to “RMT_DSPL” on page 4-24.
Remote
A 1 1
Lock
Meas
Trigger
Error Integ
Repeat
Output
S-ch
M-ch
C
Label Description
Remote Remote status indicator. The triangle mark appears when the Keysight
E5260/E5270 is in the remote condition.
Lock Key status indicator. The triangle mark appears when the front panel keys are
locked by an external computer.
Meas Measurement status indicator. The triangle mark appears when the measurement
has been performed. Then you cannot change the channel setup. If the time to get
one measurement data item is too short, the triangle mark is not displayed.
Trigger Trigger wait mode. C: GPIB command, S: Step source start, or M: Step
measurement start. The trigger function is available for the GPIB remote
condition. See Programming Guide.
Error Error status indicator. The triangle mark appears when any error has occurred.
Integ A/D converter operation mode. A: Auto, M: Manual, or P: PLC. For details, see
“Measure key group” on page 4-11.
Output Output status indicator. The triangle mark appears while the source output is
being applied by the channel specified by S-ch. For the Keysight E5270B, if ASU
(Atto Sense and Switch Unit) connects to the AUX side, not SMU side, the
reversed triangle mark appears.
Repeat Repeat measurement status indicator. The triangle mark appears when the repeat
measurement mode is selected.
M-ch Measurement channel number effective for the data displayed in the Meas Data
area. 1 or 2 for 2-ch, one of 1 to 8 for 8-ch mainframe.
S-ch Source channel number effective for the data displayed in the Setup Data area. 1
or 2 for 2-ch, one of 1 to 8 for 8-ch mainframe.
