Keysight E5260/E5270 User’s Guide, Edition 6 5-19
Front Panel Operations
Applying Source Output
To Use Series Resistor
This instruction connects the series resistor to the specified channel internally.
1. Press the
Shift
key and the
On/Off
key.
2. Press the arrow keys, and select ON to connect the series resistor.
3. Press the
OutCh
key if you are setting the resistor for another channel, and
perform 2.
4. Press the
Enter
key to make the setup effective, or press the
Exit
key to cancel
changing the setup.
NOTE A series resistor is mounted on each module. If you use a series resistor, the voltage
you set is applied to the near side of the series resistor. Thus, the voltage will be
divided by the series resistor and the device under test.
The series resistor cannot be used for the measurements that use the high resolution
SMU (HRSMU) connected to the Atto Sense and Switch Unit (ASU) or the
measurements that use 1 A range of the high power SMU (HPSMU).
To Use Filter
This procedure connects the filter to the specified channel internally.
1. Press the
Shift
key and the
V/I
key.
2. Press the arrow keys, and select ON to connect the filter.
3. Press the
OutCh
key if you are setting the filter for another channel, and perform
2.
4. Press the
Enter
key to make the setup effective, or press the
Exit
key to cancel
changing the setup.
NOTE A filter is mounted on each module. It assures clean source output with no spikes or
overshooting.
