3-24 Keysight E5260/E5270 User’s Guide, Edition 6
Installation
Mounting Connectors
Mounting Connectors
Previous sections described how to install the available accessories, and Keysight
16495 Installation Guide provides the information on how to install connector
plates on the shielding box. However, you may choose to mount connectors directly
on your own connector plate or test fixture.
To do this, you will need to make connector holes and mount the connectors
yourself. This section contains information on connector hole dimensions.
To mount connectors:
1. Select the appropriate parts for your application. See Table 3-3.
2. Make the holes and mount the connectors. See Table 3-4.
For Kelvin connections, use the Keysight 16493K Kelvin triaxial cable. The
Kelvin triaxial cable requires a Kelvin triaxial connector, which has two
connector holes and three screw holes.
3. Build the interlock circuit shown in “To Make an Interlock Circuit” on page
3-26.
4. Attach cables from the connectors to the DUT (device under test). Refer to “To
Connect the GNDU Output” on page 3-29, “To Connect the SMU Output” on
page 3-30.
WARNING For safety, prepare and attach a shield cover to avoid touching the joints on the
wiring side of connectors. And ground the cover.
Wrap an insulator around the naked conductors of coaxial cable to avoid
touching it.
Pour des raisons de sécurité, préparez et fixez un couvercle protecteur pour
éviter de toucher les joints du côté du câblage des connecteurs. Et mettez le
couvercle à la terre.
Enroulez un isolant autour des conducteurs dénudés du câble coaxial afin
d'éviter de les toucher.
