Keysight E5260/E5270 User’s Guide, Edition 6 3-9
Installation
Inspection and Installation
WARNING If the Circuit Common terminal is not connected to the frame ground terminal
(for floating measurement), a potential shock hazard may present. Do not
touch any of measurement circuit at any time while a floating measurement is
in progress.
Si la borne Circuit Common n'est pas connectée à la borne de terre du cadre
(pour des mesures de flotte), il peut y avoir un risque de choc électrique. Ne
touchez aucun circuit de mesure à n'importe quel moment quand la mesure de
flotte est en cours.
3. Connect the power cable from the instrument to an AC power outlet.
4. Press the Line switch to turn on the instrument.
The initialization screen will appear on the display of the instrument. And the
power-on self-test is automatically executed.
If the instrument is operating correctly, the LCD displays as shown in Figure
3-1.
If a problem occurs, see If You Have a Problem.
5. Press the
Menu
key, and select CONFIG and UNIT menu. Then make sure that
the modules displayed match the modules installed.
6. Press the
Exit
key three times to close the setup menu.
Figure 3-1 LCD Display Example
To Execute Diagnostics and Self-calibration
Perform the following functions as necessary.
Self-test See “To Perform Self-test” on page 5-7.
Self-calibration See “To Perform Self-Calibration” on page 5-8.
Diagnostics See “To Perform Diagnostics” on page 5-9.
Meas Value #1 Meas Value #2
Setting Parameter
Stat
OUT: 0.00 V
CPL: 100.0uA
OFF
Remot e
A 1 1
Shift
Lock
Meas
Tr igg er
Erro r
Integ
Repeat
Ou tpu t
S-ch
M-ch
