4-18 Keysight E5260/E5270 User’s Guide, Edition 6
Front Panel Reference
Setup Menus
Setup Menus
This section explains the following setup menus displayed in the Change Setup area.
• “Setup Menu”
• “Calibration and Test Menu”
• “Measurement Range Setup Menu”
• “Output Range Setup Menu”
Setup Menu
Press the
Menu
key. The setup menu is displayed in the Change Setup area as shown
in the following example. The setup menu is used to change the GPIB address,
power line frequency, monitor items, data display format, and so on.
Press the arrow key to move the cursor to the desired function name. Then, press the
Enter
key. The setup message or the sub menu will be displayed. To return to the
previous menu, press the
Exit
key.
-123.456mA -1.23456mV OUT:-123.4mV
CONFIG MON_ITEM DSPL_FRMT >
-123.456mA -1.23456mV OUT:-123.4mV
<WAIT_TIME ERROR RMT_DSPL BEEP
To Next Page
