5-22 Keysight E5260/E5270 User’s Guide, Edition 6
Front Panel Operations
Making Measurement
To Measure DC Current/Voltage
The following procedure performs DC current or voltage measurement using the
specified measurement and source channel.
1. Press the
OutCh
key repeatedly to specify the source and measurement channel.
The channel number must appear in the S-ch status area.
2. Confirm that the Output status indicator does not show the output enable status.
If the source output has been enabled, press the
On/Off
key. This disables the
source output.
3. Press the
MeasCh
key repeatedly to specify the source and measurement
channel. The channel number displayed in the M-ch status area must be same as
the channel number displayed in the S-ch status area.
4. Press the
MeasItem
key repeatedly to select the measurement item. See “To
Select Measurement Item” on page 5-23.
5. Press the
MeasRange
key to set the measurement range. See “To Select
Measurement Range” on page 5-24.
6. Press the
Integ
key repeatedly to select the A/D converter operation mode. See
“To Set A/D Converter” on page 5-25.
7. Change the source output value if necessary. See “To Apply DC
Current/Voltage” on page 5-16.
8. Press the
On/Off
key to enable the source output. The measurement channel
Output status must be ON to perform the measurement.
9. Press the
Single
key to execute a spot measurement.
Or press the
Repeat
key to execute repeat measurements.
NOTE To stop the repeat measurement, press the
Single
key.
To change the source output value or the compliance value during measurement, see
“To Set Output/Compliance Value” on page 5-17.
To stop source output and measurement of the channel specified by the S-ch status,
press the
On/Off
key.
