5-8 Keysight E5260/E5270 User’s Guide, Edition 6
Front Panel Operations
Setting Up Keysight E5260/E5270
To Perform Self-Calibration
1. Open the measurement terminals of the Keysight E5260/E5270.
2. Press the
Shift
key and the
Menu
key.
3. Move the cursor to CAL, then press the
Enter
key.
4. Move the cursor to EXECUTE, then press the
Enter
key.
5. Press the arrow keys to select the slot to calibrate; ALL or Slot n (n: 1 or 2 for
2-ch mainframe, 1 to 8 for 8-ch mainframe).
6. Press the
Enter
key to start calibration, or press the
Exit
key to cancel calibration.
During calibration, press the
Exit
key to abort it.
7. Press the
Exit
key three times to close the setup menu.
To display calibration results
1. Press the
Shift
key and the
Menu
key.
2. Move the cursor to CAL, then press the
Enter
key.
3. Move the cursor to RESULT, then press the
Enter
key.
4. Press the arrow keys to select the calibration item; FRAME or Slot n (n: 1 or 2
for 2-ch mainframe, 1 to 8 for 8-ch mainframe). The calibration result is
displayed for each calibration item.
5. Press the
Exit
key three times to close the setup menu.
NOTE To use a module that failed self-calibration, refer to “To use modules that failed
self-test” on page 5-7. The procedure also applies to modules that failed
self-calibration.
NOTE If you execute the CAL of the E5270B installed with the ASU (Atto Sense and
Switch Unit), the E5270B executes the self-calibration and the 1 pA range offset
measurement for the measurement channels connected to the ASUs. The offset data
is temporarily memorized until the E5270B is turned off, and is used for the
compensation of the data measured by the 1 pA range of the channels. The E5270B
performs the data compensation automatically and returns the compensated data.
Since the E5270B is turned on, if you do not execute the CAL, the E5270B performs
the data compensation by using the pre-stored offset data.
