5-16 Keysight E5260/E5270 User’s Guide, Edition 6
Front Panel Operations
Applying Source Output
To Apply DC Current/Voltage
The following procedure applies a DC bias using a source channel. To use multiple
source channels, perform the procedure for all source channels.
1. Press the
OutCh
key repeatedly to specify the source channel.
The channel number must appear in the S-ch status area.
2. Confirm that the Output status indicator does not show the output enable status.
If the source output has been enabled, press the
On/Off
key. This disables the
source output.
3. Press the
OutRange
key to select the output range.
See “To Set Output Range” on page 5-18.
4. Press the
Shift
key and the
On/Off
key if you are using a series resistor.
See “To Use Series Resistor” on page 5-19.
5. Press the
Shift
key and the
V/I
key if you are using a filter.
See “To Use Filter” on page 5-19.
6. If you are using the Keysight E5270B installed with the high resolution SMU
(HRSMU) and if you want to change the internal connection of the ASU (Atto
Sense and Switch Unit), see “To Switch ASU Internal Connection” on page
5-20.
7. Press the
OUT Value
key or the
CPL Value
key to set the source output value or the
compliance value.
See “To Set Output/Compliance Value” on page 5-17.
8. Press the
On/Off
key to enable the source output.
NOTE To change the source output value or the compliance value during source output, see
“To Set Output/Compliance Value” on page 5-17.
To stop source output of the channel specified by the S-ch status, press the
On/Off
key.
