4-32 Keysight E5260/E5270 User’s Guide, Edition 6
Front Panel Reference
Setup Menus
Output Range Setup Menu
Press the OutRange key to display the output range setup menu. The output range
setup menu is displayed in the Change Setup area as shown below. The menu is used
to set the voltage output ranging mode (V_RANGE) or the current output ranging
mode (I_RANGE).
Press the arrow key to move the cursor to the desired function name. Then, press the
Enter key.
V_RANGE Displays the following message.
[S-ch #] Output Range: Mode
where # is 1 or 2 for the 2-ch mainframe, 1, 2, ... or 8 for the 8-ch mainframe, and
Mode is the output ranging mode, AUTO, FIX xV, or LIM xV. Then, x indicates the
range value. Available values depend on the module.
AUTO means auto ranging, FIX means fixed range, and LIM means limited auto
ranging.
Press the arrow key to select the output ranging mode. Then, press the
Enter key to
make the setup effective, or press the
Exit key to cancel changing the setup.
I_RANGE Displays the following message.
[S-ch #] Output Range: Mode
where # is 1 or 2 for the 2-ch mainframe, 1, 2, ... or 8 for the 8-ch mainframe, and
Mode is the output ranging mode, AUTO, FIX xA, or LIM xA. Then, x indicates the
range value. Available values depend on the module.
AUTO means auto ranging, FIX means fixed range, and LIM means limited auto
ranging. Also, uA means μA.
Press the arrow key to select the output ranging mode. Then, press the
Enter key to
make the setup effective, or press the
Exit key to cancel changing the setup.
-123.456mA -1.23456mV OUT:-123.4mV
V_RANGE I_RANGE
