Keysight E5260/E5270 User’s Guide, Edition 6 7-3
If You Have a Problem
When You Install the E5260/E5270
When You Install the E5260/E5270
This section covers the following basic problems that you may encounter when you
install the E5260/E5270, and the solutions.
• “If the E5260/E5270 cannot be Powered on”
• “To Simplify the Connections”
If the E5260/E5270 cannot be Powered on
• Check that the power cable is firmly connected to the E5260/E5270 and to
power outlet.
• Check that the front-panel Line switch is on.
To Simplify the Connections
If you want to simplify the measurement connections, use the triaxial cables instead
of the kelvin triaxial cables, and connect the triaxial cables between the Force
terminals and the test fixture or the connector plate. Then the Sense terminals must
be opened.
NOTE The Keysight E5260/E5270 has the Force and Sense terminals to make the kelvin
connection. And the kelvin triaxial cables are effective to extend the measurement
terminals near by the device under test. Connecting the Force and Sense lines
together at the device terminals can minimize the measurement error caused by the
residual resistance of the connection cables. The kelvin connection is effective for
the low resistance measurement and the high current measurement. Also it is one of
the conditions to satisfy the measurement specifications of the Keysight
E5260/E5270.
