4-16 Keysight E5260/E5270 User’s Guide, Edition 6
Front Panel Reference
Front Panel Key Details
V/I Switches the source output mode, voltage output or current output.
Pressing the
V/I
key changes the output mode immediately. It also changes the
measurement item as shown below:
Filter
(Shift+V/I)
Displays the following message.
[S-ch #] Filter: ON or OFF
where # is 1 or 2 for the 2-ch mainframe, 1, 2, ... or 8 for the 8-ch mainframe.
Press the
OutCh
key to specify the source channel, and press the arrow key to
connect the filter (ON) to the channel or disconnect it (OFF). Then, press the
Enter
key to make the setup effective, or press the
Exit
key to cancel changing the setup.
A filter is mounted on each module. It assures clean source output with no spikes or
overshooting.
Source Output Mode OUT CPL Meas Data 1 Meas Data 2
V (voltage output) Voltage Current Current
Current Voltage
Power
Resistance
I (current output) Current Voltage Voltage
Voltage Current
Power
Resistance
To Next Page
