3-14 Keysight E5260/E5270 User’s Guide, Edition 6
Installation
Installing Accessories
WARNING This instrument supports the Interlock function to prevent you from receiving
an electrical shock from high voltage (more than ± 42 V). If the Interlock
terminal is open, this instrument cannot apply high voltage more than ± 42 V.
If you do not use the 16442A/B test fixture, install an interlock circuit (see page
3-26) and connect it to the Interlock terminal.
Cet instrument prend en charge la fonction de verrouillage afin d'éviter que
vous ne receviez un choc électrique par haute tension (plus de ± 42 V). Si la
borne de verrouillage est ouverte, cet instrument ne peut pas appliquer de
haute tension à plus de ± 42 V.
Si vous n'utilisez pas l'équipement de test 16442A/B, installez un circuit de
verrouillage (voir page 3-26) et connectez-le à la borne de verrouillage.
CAUTION The GNDU can sink current of up to 4 A (E5260A/E5270B) or 2.2 A
(E5262A/E5263A). Use Keysight 16493L GNDU cable to connect the GNDU to a
test fixture or a connector plate.
Do not use normal triaxial cable (16494A) because the maximum current rating of
the cable is 1 A.
CAUTION Never connect the Guard terminal to any output, including circuit common, chassis
ground, or any other guard terminal. Doing so will damage the SMU.
To Next Page
