3-16 Keysight E5260/E5270 User’s Guide, Edition 6
Installation
Installing Accessories
To Connect 16442B
Use the following cables to connect from the E5260/E5270 connectors to the
16442B’s relative connectors.
NOTE Making non-Kelvin connection
The Force terminals can be used to force and measure DC voltage or current. If you
want to simplify the cable connections, open the Sense terminals and connect the
Force terminals only to the test fixture by using the triaxial cables.
If you make the kelvin connection, use both Force and Sense terminals. Connecting
the Force and Sense lines together at the terminal of the device under test minimizes
the measurement error caused by the residual resistance of the connection cables.
The kelvin connection is effective for the low resistance measurement and the high
current measurement.
Cables
16442B
Terminals
E5260/E5270
Terminals
Keysight 16493J Interlock Cable, 3 m or 1.5 m Intlk Interlock
Keysight 16493L GNDU Cable, 3 m or 1.5 m GNDU GNDU
For Kelvin connection:
Keysight 16493K Kelvin Triaxial Cable, 3 m
or 1.5 m
Up to 3 SMUs can be connected to the 16442B
by the Kelvin connection.
SMU1 SMU Force
SMU2 Sense
SMU3 SMU Force
SMU4 Sense
SMU5 SMU Force
SMU6 Sense
For non-Kelvin connection:
Keysight 16494A Triaxial Cable, 3 m or 1.5 m
Up to 6 SMUs can be connected to the 16442B
by the non-Kelvin connection.
SMU1 SMU Force
SMU2 SMU Force
SMU3 SMU Force
SMU4 SMU Force
SMU5 SMU Force
SMU6 SMU Force
