3-18 Keysight E5260/E5270 User’s Guide, Edition 6
Installation
Installing Accessories
Table 3-2 To Connect Connector Plate
NOTE Use the Keysight 16494B Kelvin Triaxial Cable to connect to the Keysight E5250A
Low Leakage Switch Mainframe or the connector plate for the Keysight 4142B
Modular DC Source/Monitor by the kelvin connection.
Cables
Connector
Plate
E5260/E5270
Terminals
Keysight 16493J Interlock Cable, 3 m or 1.5 m Intlk Interlock
Keysight 16493L GNDU Cable, 3 m or 1.5 m GNDU GNDU
For Kelvin connection:
Keysight 16493K Kelvin Triaxial Cable, 3 m
or 1.5 m
Up to 4 SMUs can be connected to the 16495J
by the Kelvin connection.
Up to 6 SMUs can be connected to the 16495F
by the Kelvin connection.
Up to 3 SMUs can be connected to the
16495H by the Kelvin connection. Connectors
7 and 8 are not triaxial.
1SMUForce
2Sense
3SMUForce
4Sense
5SMUForce
6Sense
7SMUForce
8Sense
For non-Kelvin connection:
Keysight 16494A Triaxial Cable, 3 m or 1.5 m
Up to 8 SMUs can be connected to the 16495J
by the non-Kelvin connection.
Up to 6 SMUs can be connected to the
16495H by the non-Kelvin connection.
Connectors 7 and 8 are not triaxial.
1SMUForce
2SMUForce
3SMUForce
4SMUForce
5SMUForce
6SMUForce
7SMUForce
8SMUForce
