9 Programming the Instrument
9.4 Status Register System & STATus Subsystem
Bit Condition Operation
0 ODI Connection Error ODI Connection Error
This bit is never triggered, only its aliases are
Filter Registers
–
"Questionable Integrity Output Condition" on page 1150
–
"Questionable Integrity Output Enable" on page 1150
–
"Questionable Integrity Output Event Query" on page 1151
–
"Questionable Integrity Output Negative Transition" on page 1151
–
"Questionable Integrity Output Positive Transition" on page 1152
Questionable Integrity Output Condition
Returns the decimal value of the sum of the bits in the Questionable Integrity Output
Condition register.
NOTE
The data in this register is continuously updated and reflects the current
conditions.
Remote
Command
:STATus:QUEStionable:INTegrity:OUTPut:CONDition?
Example
:STAT:QUES:INT:OUTP:COND?
Preset 0
Status Bits/OPC
dependencies
Sequential command
Questionable Integrity Output Enable
Determines which bits in the "Questionable Integrity Output Condition" on page
1150 register will set the corresponding bit in the "Questionable Integrity Output
Event Query" on page 1151 register, which also sets the Data Output Summary bit
(bit 2) in the "Questionable Integrity Register" on page 1142.
The variable <integer> is the sum of the decimal values of the bits that you want to
enable.
Remote
Command
:STATus:QUEStionable:INTegrity:OUTPut:ENABle
:STATus:QUEStionable:INTegrity:OUTPut:ENABle?
Example
:STAT:QUES:INT:OUTP:ENAB 1
IQ Analyzer Mode User's &Programmer's Reference 1150
