4.2.1.20 Object 2014-2017h: 1st-4th Mask 1 to 4 for Transmit-PDO
In order to reduce the bus loading with event-triggered PDOs, masking can be used to switch off the
monitoring for individual bits in the PDO. In this way it can be arranged, for instance, that actual
position values are only signaled once per turn.
This Object masks the PDO-channels 1 to 4. If only two bytes have been defined in a PDO, then it
masks just two bytes, although 4 bytes of mask information have been transmitted.
An activated bit in the mask means that monitoring is active for the corresponding bit in the PDO.
Index
2014
h
to 2017
h
Name
tx_mask 1 to 4
Object code
ARRAY
Number of elements
2
Data type
UNSIGNED32
Sub-index 1
Description
tx_mask1 to 4_low
Mode
independent
Access
rw
PDO mapping
not possible
Unit
—
Value range
UNSIGNED32
EEPROM
no
Default value
FFFFFFFF
h
Sub-index 2
Description
tx_mask1 to 4_high
Mode
independent
Access
rw
PDO mapping
not possible
Unit
—
Value range
UNSIGNED32
EEPROM
no
Default value
FFFFFFFF
h
4.2.1.21 Object 2030h: DP-RAM Variables (write only)
Index 2030
h
Name
DP-Ram Variables, write only (PDO)
Object code
ARRAY
Data type
INTEGER32
Category
optional
Subindex 0
Description
Number of entries
Data type
UNSIGNED8
Category
optional
Access
ro
PDO mapping
not possible
Value range
9
Default value
9
Subindex 1...8
Description
DP-Ram Variables 9...16
Category
optional
Access
rww
PDO mapping
possible
Value range
INTEGER32
Default value
0
