5.2 CANopen SDOs for Safety Expansion Card S1/S2/S1-2/S2-2
The Safety expansion cards S1, S2, S3, S4 can be used with S700 from Hardware Revision 2.10
only.
5.2.1 Object 2400h: Safety card serial number
The serial number of the safety card must be filled in the configurator software. The number is prin
-
ted on the safety card front cover. It is separated to six 32 bit blocks, every byte codes one ASCII
character. End of string is coded by 0h.
Index 2400
h
Name
Safety card serial number
Object code
Record
Category
optional
Subindex 0
Description
number of entries
Data type
UNSIGNED8
Category
optional
Access
ro
PDO mapping
not possible
Value range
6
Default value
6
Subindex 1 to 6
Description
Safety card serial number part 1 to 6
Data type
UNSIGNED32
Category
optional
Access
ro
PDO mapping
not possible
Value range
UNSIGNED32
Default value
—
5.2.2 Object 2401h: Safety card status
Index 2401
h
Name
Safety card status
Object code
VAR
Data type
UNSIGNED32
Category
optional
Access
ro
PDO mapping
possible
Value range
UNSIGNED32
Default value
—
Bit Meaning
0 Status LED ‘POWER’ on safety card front cover
1 Status LED ‘RUN’ on safety card front cover
2 Status LED ‘CONFIG’ on safety card front cover
3 Status LED ‘FAULT’ on safety card front cover
4 Status internal ‘STO’ (0 = STO not active, 1 = STO active)
5 OK message if configuration data download was successful
8 Bit is set if safety card status is ‘STARTUP’
9 Bit is set if safety card status is ‘RUN’
10 Bit is set if safety card status is ‘STOP’
11 Bit is set if safety card status is ‘CONFIG’
