5 Appendix
5.1 The Object Channel
5.1.1 Objects >3500h Manufacturer specific object channel
The Object Dictionary has been expanded beyond Index 3500
h
(reserved object range 3500
h
...
3900
h
) for all Device Objects that can be described in up to 4 bytes of user data.
This range can be dynamically extended, i.e. if extensions are made, new device parameters that
fulfil the above-mentioned format are automatically added to the table for the core firmware.
Object 3500
h
(Subindex 01
h
, read) can be used to show the total number of objects in the Object
Channel (Þ p.101).
The objects in the Object Channel (ASCII parameters) cannot be mapped in a PDO!
Each object in this range is described with the aid of 8 Sub-indices. The structure is built up as fol
-
lows:
Index > 3500
h
Name
Object-dependent
Object code
VAR
Data type
RECORD
Subindex 0
Description
number of entries
Unit
—
Access
—
PDO mapping
not possible
Data type
UNSIGNED8
Value range
0 ... 2
8
-1
EEPROM
—
Default value
—
Subindex 1
Description
read/write a parameter
Unit
see corresponding ASCII command
Access
see corresponding ASCII command
PDO mapping
not possible
Data type
see corresponding ASCII command, transmission always as INTEGER32
Value range
see corresponding ASCII command
EEPROM
see Subindex 4
Default value
see corresponding ASCII command
Subindex 2
Description
read lower limit value
Unit
see corresponding ASCII command
Access
ro
PDO mapping
not possible
Data type
see corresponding ASCII command
Value range
see corresponding ASCII command
EEPROM
—
Default value
—
Subindex 3
Description
read upper limit value
Unit
see corresponding ASCII command
Access
ro
PDO mapping
not possible
Data type
see corresponding ASCII command
Value range
see corresponding ASCII command
EEPROM
—
Default value
—
CANopen for S300/S700 91
Kollmorgen 11/2018 Appendix
