Ch.7 Optional Functions
< 176 >
REGIUS Console CS-3 OPERATION MANUAL Ver. 1.10 2005.2
Composite Image Adjust Screen
Adjusts the position of joint borders of the images selected in the “Composite Image
Select” screen.
Composite Image
Select screen
Composite Image
Adjust Screen
Enlarged Stitched Image
Enlarges and displays the image area select-
ed (framed in blue) in the “Whole Stitched
Images” screen. Magnification may be set
using the zoom slider.
Whole Stitched Images
Select in the “Whole Stitched Images” the area that
shall be enlarged and displayed. The area enlarged is
indicated with the blue frame. The size of the blue
frame changes by the setting of zoom slider.
To Next Page
