Ch.8 Operating the Optional Equipments
< 186 >
REGIUS Console CS-3 OPERATION MANUAL Ver. 1.10 2005.2
Hands-free Usage
When the bar code reader is set into its stand, laser outputs continuously: thus bar code reading may
be carried out at any time without using the trigger.
1 Hold the bar code label on the cassette in front of
the reading window on the bar code reader.
• Since laser outputs continuously, the reading
process commences automatically.
2 Hold the cassette so that the bar code label of the
cassette is placed against the single bar code
reader.
• Reading starts.
• Successful completion of reading will be indicated by
a short beep tone and illumination of a green LED
indicator.
When using the bar code reader with a hands-free mode, the laser outputs continu-
ously. Be sure to avoid that the laser is radiated into eyes directly.
When reading the bar code, ensure that the laser scanning line crosses all the bars
and spaces.
