2NC/2NF/2NG/2NN/3P7/3P8/3P9
1-5-80
(11)Detaching and refitting the inner cover
Pocedure
1. Remove four screws.
2. Remove the inner cover with the front
cover.
Figure 1-5-142
Screw
Screw
Screw
Screw
Front cover Inner cover
Hook
