Kyocera DP-480

2NC/2NF/2NG/2NN/3P7/3P8/3P9
1-5-5
(1-1) Detaching and refitting the primary paper feed unit and the pickup roller
Procedure
1. Remove the cassette by pulling out for-
ward from main unit.
Figure 1-5-6
2. Remove the screw.
3. emove the cassette by pulling out for-
ward from main unit.
Figure 1-5-7
Cassette
Main unit
Primary paper feed unit
Screw
Main unit
