2NC/2NF/2NG/2NN/3P7/3P8/3P9
1-3-18
U019 Firm Version
Description
Displays the part number of the ROM fitted to each board.
Purpose
To check the part number or to decide, if the newest version of ROM is installed.
Method
1. Press the start key. The ROM version are displayed.
2. Change the screen using the cursor up/down keys.
Display Description
Main Main ROM
MMI Operation ROM
Engine Engine ROM
Engine Boot Engine booting
Option Language Optional language ROM
DP Document processor ROM
DP Boot Document processor booting
PF1 Paper feeder1 ROM
PF1 Boot Paper feeder1 booting
PF2 Paper feeder2 ROM
PF2 Boot Paper feeder2 booting
PF3 Paper feeder3 ROM
PF3 Boot Paper feeder3 booting
Completion
Press the stop key. The screen for selecting a maintenance item No. is displayed.
