Kyocera DP-480 - Page 411

2NC/2NF/2NG/2NN/3P7/3P8/3P9
2-2-21
16. Unhook two hooks using flat screw
driver and then remove the front left
cover by pulling upward.
Figure 2-2-19
17. Remove the keft tray.
Figure 2-2-20
Flat screwdriver
Front left cover
Hooks
Left tray
