Kyocera DP-480

2NC/2NF/2NG/2NN/3P7/3P8/3P9-1
2-2-26
(3) Connector lists
Connector Pin Signal I/O Voltage Description
TB1
1AC LIVE
I 120 V AC
220-240 V AC
AC power input
Connect to
inlet
TB2
1 AC NEUTRAL
I 120 V AC
220-240 V AC
AC power input
Connect to
inlet
TB5
1 HCOM I
120 V AC
220-240 V AC
AC power input
Connect to
fuse themo-
stat
CN1
1 +24V0 O 24 V DC 24 V DC power output to M/EPWB
Connect to
main/engine
PWB
2 GND - - Ground
CN2
1 MHREM I 0/3.3 V DC MH: On/Off
Connect to
main/engine
PWB
2 SHREM I 0/3.3 V DC SH: On/Off
3 RELAYREM I 0/3.3 V DC Power relay signal: On/Off
4 ZCROSS I 0/3.3 V DC Zero-cross signal
5 +24VIL I 24 V DC 24 V DC power output to M/EPWB
CN3
1LIVE O
120 V AC
220-240 V AC
AC power output to CH
Connect to
cassette
heater
2LIVE O
120 V AC
220-240 V AC
AC power output to PFCH
3 NC - - Not used
4 NC - - Not used
5NEUTRAL O
120 V AC
220-240 V AC
AC power output to CH
6NEUTRAL O
120 V AC
220-240 V AC
AC power output to PFCH
CN4
1MH O
120 V AC
220-240 V AC
MH: On/Off
Connect to
fuse heater1,
2
2SH O
120 V AC
220-240 V AC
SH: On/Off
