Kyocera DP-480

2NC/2NF/2NG/2NN/3P7/3P8/3P9
2-2-35
YC4
17 GND
- - Ground
Connected to
DP original
sensor, DP
original feed
sensor, DP
registration
sensor, DP
open/close
sensor, DP
shiftback
sensor and
DP timing
sensor
18 TIMING_SW
0/3.3 V DC DPTS: On/Off
YC6
13.3V2
O 3.3 V DC 3.3 V DC power output to DPMPWB
Connected to
DP original
lengyh switch
and DP
original width
switch
2GND
- - Ground
3 LS_SW
0/3.3 V DC DPOLSW: On/Off
4WIDE3
0/3.3 V DC DPOWSW: On/Off
5WIDE2
0/3.3 V DC DPOWSW: On/Off
6GND
- - Ground
7WIDE1
0/3.3 V DC DPOWSW: On/Off
YC7
1CL_REM
0/24 V DC DPRCL: On/Off
Connected to
DP original
feed motor,
DP original
conveying
motor, DP
shiftback
motor and
DP regist
clutch
2 24VIL_DP
O 24 V DC 24 V DC power output to DPMPWB
3JNC_MOT_/B
0/24 V DC(pulse) DPSBM drive control signal
4JNC_MOT_/A
0/24 V DC(pulse) DPSBM drive control signal
5JNC_MOT_B
0/24 V DC(pulse) DPSBM drive control signal
6JNC_MOT_A
0/24 V DC(pulse) DPSBM drive control signal
7CONV_MOT_/
B
0/24 V DC(pulse) DPOCM drive control signal
8CONV_MOT_/
A
0/24 V DC(pulse) DPOCM drive control signal
9CONV_MOT_
B
0/24 V DC(pulse) DPOCM drive control signal
10 CONV_MOT_
A
0/24 V DC(pulse) DPOCM drive control signal
11 FEED_MOT_/
B
0/24 V DC(pulse) DPOFM drive control signal
12 FEED_MOT_/
A
0/24 V DC(pulse) DPOFM drive control signal
13 FEED_MOT_
B
0/24 V DC(pulse) DPOFM drive control signal
14 FEED_MOT_
A
0/24 V DC(pulse) DPOFM drive control signal
Connector Pin Signal I/O Voltage Description
