Hydraulic System 281
6. Remove the strainer from the tank port along with the shut-off valve (ball valve) [see Figure
5-24].
7. Unscrew the strainer.
The strainer has to be turned counter-clockwise to be removed.
8. Clean the strainer using solvent, and check for damage; replace if necessary.
9. Apply thread seal compound on the strainer threads and reinstall the strainer.
10. Replace the seal, if necessary [see Figure 5-24].
Figure 5-23
Suction line
Figure 5-24
Strainer
Clamps
Suction
hose
Shut-off
valve
Strainer
Seal
Flange
