Chapter 13:
Theory of Operations
FPGA Programming Connector
Pin # Xilinx Program Interface
1 +5V
2 GND
3 CCLK
4 NC (INIT)
5 DONE
6 DIN
7 -PROGRAM
The FPGA on all cards is programmable from the local microprocessor for normal
operation. If the FPGA programming connector is to be used, a jumper disables the
microprocessor control. The procedure for programming the FPGA device under
software control is as follows:
1. Drive "FPGA_prog" inactive to start.
93
