M.2 adapter and M.2 drive replacement
Use this information to remove and install the M.2 adapter and M.2 drive.
The position of the M.2 module
1 vary by server hardware configuration. This topic uses the M.2 module on
the standard air baffle as an example for replacement illustration. The replacement procedure is the same for
the others.
Table 25. M.2 module position
Figure 186. On standard air baffle
Figure 187. On GPU air baffle
Figure 188. On 8 x 2.5 middle drive cage Figure 189. On 4 x 3.5 middle drive cage
• “Remove the M.2 adapter and M.2 drive” on page 245
• “Adjust the retainer on the M.2 adapter” on page 247
• “Install the M.2 adapter and M.2 drive” on page 248
