Memory module replacement
Use this information to remove and install a memory module.
• “Remove a memory module” on page 250
• “Memory module installation rules and order” on page 253
• “Install a memory module” on page 269
Remove a memory module
Use this information to remove a memory module.
About this task
Attention:
• Read “Installation Guidelines” on page 185 to ensure that you work safely.
• Memory modules are sensitive to static discharge and require special handling. Refer to the standard
guidelines for “Handling static-sensitive devices” on page 188.
– Always wear an electrostatic-discharge strap when removing or installing memory modules.
Electrostatic-discharge gloves can also be used.
– Never hold two or more memory modules together so that they touch. Do not stack memory modules
directly on top of each other during storage.
– Never touch the gold memory module connector contacts or allow these contacts to touch the outside
of the memory module connector housing.
– Handle memory modules with care: never bend, twist, or drop a memory module.
– Do not use any metal tools (such as jigs or clamps) to handle the memory modules, because the rigid
metals may damage the memory modules.
– Do not insert memory modules while holding packages or passive components, which can cause
package cracks or detachment of passive components by the high insertion force.
A video for this task is available at:
• Youtube:
https://www.youtube.com/playlist?list=PLYV5R7hVcs-DqVplE36HIvdM_sq_Auw3U
• Youku: https://list.youku.com/albumlist/show/id_59643657.html
Procedure
Step 1. If any of the modules to be removed is PMEM:
• In the case of system board replacement, keep records of the slots in which the modules are
installed, and make sure to install them back to the exact same slots after system board
replacement.
• If the removed PMEM is to be replaced or reused in a different configuration, make sure to
complete the following procedure before physically removing the module.
Attention: Without the following steps being completed, the removed PMEM will not be usable
in another system or configuration.
1. Back up stored data in PMEM namespaces.
2. Disable PMEM security with one of the following options:
– LXPM
250
ThinkSystem SR650 V2Maintenance Manual
