RAID super capacitor modules
Use this section to understand the cable routing for RAID super capacitor modules.
The location of RAID super capacitor modules varies by the server hardware configurations.
Figure 23. On the chassis
Figure 24. On standard air baffle
Figure 25. On GPU air baffle Figure 26. On the 2.5-inch middle drive cage
