Install a system fan
Use this information to install a system fan.
About this task
S033
CAUTION:
Hazardous energy present. Voltages with hazardous energy might cause heating when shorted with
metal, which might result in spattered metal, burns, or both.
S017
CAUTION:
Hazardous moving fan blades nearby. Keep fingers and other body parts away.
Attention:
• Read “Installation Guidelines” on page 185 to ensure that you work safely.
• When installing a hot-swap fan without powering off the server, do not touch the system fan cage. With
power on, complete the replacement within 30 seconds to ensure proper operation.
• Prevent exposure to static electricity, which might lead to system halt and loss of data, by keeping static-
sensitive components in their static-protective packages until installation, and handling these devices with
an electrostatic-discharge wrist strap or other grounding system.
A video for this task is available at:
• Youtube:
https://www.youtube.com/playlist?list=PLYV5R7hVcs-DqVplE36HIvdM_sq_Auw3U
• Youku: https://list.youku.com/albumlist/show/id_59643657.html
Procedure
Step 1. Touch the static-protective package that contains the new system fan to any unpainted surface on
the outside of the server. Then, take the new system fan out of the package and place it on a static-
protective surface.
Step 2. Position the system fan above the system fan cage. The system fan connector on the bottom of the
system fan should face the rear of the chassis. Press the system fan straight down until it is seated
into place.
366
ThinkSystem SR650 V2Maintenance Manual
