Lenovo ThinkSystem SR650 V2 - Page 293

Server rear configuration Riser 1 cage Riser 2 cage Riser 3 cage
Configuration with an 8 x
2.5-inch rear drive cage
• Type 1: 3FH riser cage
• Type 2: 2FH + 7mm riser
cage
• Type 3: 1FH riser cage
• Type 4: 7mm riser cage
Configuration with a 2 x
3.5-inch rear drive cage
• Type 1: 3FH riser cage
• Type 2: 2FH + 7mm riser
cage
• Type 3: 1FH riser cage
• Type 4: 7mm riser cage
Configuration with a 4 x
3.5-inch rear drive cage
Type 3: 1FH riser cage
• Type 3: 1FH riser cage
• Type 4: 7mm riser cage
Chapter 4. Hardware replacement procedures 283
