System Environmental Information
Sub Menu
Example
• Ambient temperature
• Exhaust temperature
• PSU status
• Spinning speed of fans by RPM
Ambient Temp: 24 C
Exhaust Temp: 30 C
PSU1: Vin= 213 w
Inlet= 26 C
FAN1 Front: 21000 RPM
FAN2 Front: 21000 RPM
FAN3 Front: 21000 RPM
FAN4 Front: 21000 RPM
Active Sessions
Sub Menu
Example
Quantity of active sessions
Active User Sessions: 1
Actions
Sub Menu Example
Several quick actions supported for users
• Restore XCC to Defaults
• Force XCC Reset
• Request XCC Reset
• Clear CMOS
• Request Virtual Reseat
• Modify XCC Static IPv4 Address/Net mask/
Gateway
• Modify System Name
• Generate/Download FFDC Service Data
• Remove FPGA Test Image
Request XCC Reset?
This will request the BMC to reboot itself.
Hold √ for 3 seconds
