Commissioning
8200SHB01995-14
4.Set the slip compensation
(
C
0
2
1
)
.
Rough setting according to motor data:
4
.
S
e
t
t
h
e
s
l
i
p
c
o
m
p
e
n
s
a
t
i
o
n
(C021).
s 
n
Nsyn
 n
r
n
Nsyn
ô 100 %
n
Nsyn

f
dr
ô 60
p
s Slip constant (C021)[%]
n
Nsyn
Synchronous motor speed [min
-1
]
n
r
Rated speed to motor nameplate [min
-1
]
f
dr
Rated frequency to motor nameplate [Hz]
p No. of pole pairs (1, 2, 3, ...)
Precise setting:
- Correct C021 until no load-dependent speed drop occurs in the required speed range between
idle running and max. motor load.
- If the values under C021 are too high, the drive may become instable (overcompensation).
- In the field frequency range between 5 Hz ... 50 Hz (87 Hz)the deviation of the rated speed is
$ 1 % (guide value). In field-weakening operation, the fault increases.
Important
- The change from V/f-characteristic control and motor-current control should only be carried out
when the controller is inhibited.
