Lenze 8200 - Types 8215 to 8218

Installation
8200SHB0199
4-11
4.1.4.1 Types 8215 to 8218
Typ Id.-NR Fert.-Nr Serien-Nr. Ei ngang1 Ei ngang2
Lenz e
Postfach 101352,31763HAMELN
a
g
b
d1
c1
f
e
3)
d3
c2
d2
h
m
n
k
l
Z
FIG 4-8 Dimensions 8215 - 8218: Assembly with thermally separated power stage
3)
With attachable fieldbus or I/O module:
Observe assembly depth and assembly space required for connection cables
[mm] a b c1 c2 d1 d2 d3 e
3)
f g h
8215 / 8216 / 8217 / 8218 162 283 31 132 10 90.5 192.5 218 88 6.5 8.5
Assembly cut-out [mm] Height Width k l m n
Line Z 250 5 132 5 16 2 147 2 19 2 266 2
