Lenze 8200 - Connection of a Brake Unit

Installation
8200SHB01994-34
4.2.7.3 Connection of a brake unit
- When connecting a brake unit (brake module with internal brake resistor or
brake chopper with external brake resistor) observe the corresponding
Operating Instructions in all cases.
Stop!
- Design the circuit so that, if the temperature monitoring of the brake unit is
activated,
- the controllers are inhibited (X5/28 = LOW),
- the mains is disconnected.
