Lenze 8200 - Single Drives with 120 % Overload

Technical Data
8200SHB0199
3-23
3.6.3 Single drives with 120 % overload
The table values are valid for operation of 82XX controllers with matching motor
and120%overloadinpumpandfandrives.
Type
Mains input L1, L2, L3, PE / motor connection U, V, W, PE
T
y
p
e
Operation with mains filter/mains choke
Fuse F1, F2, F3 E.l.c.b. Cable cross-section
1)
VDE UL VDE mm
2
AWG
8211 M6A - B6A 1 17
8212 M6A - B6A 1 17
8213 M10A - B 10A 1.5 15
8214 M10A - B 10A 1.5 15
8215 M20A - B 20A 4 11
8216 M20A - B 20A 4 11
8217 M32A - B 32A 6 10
8218 M32A - B 32A 6 10
Type
Mains input L1, L2, L3, PE / motor connection U, V, W, PE
T
y
p
e
Operation only with mains filter/mains choke
Fuse F1, F2, F3 E.l.c.b. Cable cross-section
1)
VDE UL VDE mm
2
AWG
8221 M50A 50A -- 16 5
8222 M63A 63A -- 25 3
8223 M80A 80A -- 25 3
8224 M125A 125A -- 70 2/0
8225 M160A 175A -- 95 3/0
8226 M160A 175A -- 95 3/0
8227 M200A 200A -- 120 4/0
8241 M6A 5A B6A 1 17
8242 M6A 5A B6A 1 17
8243 M10A 10A B 10A 1.5 15
8244 M10A 10A B 10A 1.5 15
8245 M20A 20A B 20A 4 11
8246 M32A 25A B 32A 6 10
1)
Observe national and regional regulations (e.g. VDE/EVU)!
