Configuration
8200SHB01997-42
7.5.11.2 Setpoint input using the keypad
Function If you select the operating mode C001 = -1-, the setpoint can be selected by means of the keypad
of the operating module.
Adjustment 1.Press key ▲ or ▼.
2.The display changes and indicates the current setpoint together with SET.
3.Set the setpoint using ▲ or ▼.
- If the controller is enabled, the changed setpoint has a direct effect on the drive.
- The setpoint is saved when the controller is inhibited. After the controller has been enabled, the
drive accelerates or decelerates tothe last setpoint.
Important Setpoints selected bymeans of the keypad are saved when separating the controller fromthe mains
or interrupting the operation. The drive can start again after controller enable!
Observe the start conditions under C142:
-
Series “Standard”: See chapter 7.8, ”Code table”.
-
Series “HVAC”: See chapter 7.9, ”Code table”.
