Network of several drives
8200SHB0199
10-1
10 Network of several drives
10.1 Function
- A DC-bus network of controllers enables the energy exchange between the
connected controllers on the DC-voltage level.
- If one or more controllers operate in generator mode (braking), the
recovered energy will be fed into the shared DC-voltage bus or the DC
source. The energy will then be available in the network of controllers which
operate in motor mode.
- The energy from the three-phase AC mains can be supplied as follows:
- Central supply via a 934X supply and feedback module.
- Decentral supply by connecting several controllers of the network to the
mains.
- The use of brake units, supply units and the energy consumption from the
three-phase AC mains can be reduced.
- The number of mains supplies can be perfectly adapted to your application.
