Installation
8200SHB0199
4-23
4.1.6 Assembly with mains filter
Note!
More information about dimensions, installation and selection of the appropriate
mains filter can be obtained from the catalog Global Drive 8200 Frequency
Inverters.
Standard assembly 1.Screw the fixing brackets to the housing of the controller and the mains filter.
2.Connect the ready-to-use output cables (unit/load) of the filter to the mains input of
the controller (L1, L2, L3, PE).
3.Use all fixing brackets to mount the unit to the assembly wall.
Assembly with thermally separated
power stage
1.For assembly preparations, see chapter 4.1.4.
2.Dismantle the housing of the mains filter.
3.Mount the controller into the assembly cut-out.
4.Connect the ready-to-use output cables of the filter (unit/load) to the mains input of
the controller (L1, L2, L3, PE).
Assembly of the variant “Cold plate” 1.For assembly preparations, see chapter 4.1.5.
2.Dismantle the housing of the mains filter.
3.Mount the controller into the assembly cut-out.
4.Connect the ready-to-use output cables of the filter (unit/load) to the mains input of
the controller (L1, L2, L3, PE).
Assembly, if the assembly space is
not deep enough
1.Mount the mains filter next to the controller.
2.Refer to the dimensions for assembly with thermally separated power stage.
