Commissioning
8200SHB01995-28
Code settings for unit 2:
Code Name Possible settings
C
o
d
e
N
a
m
e
Lenze Choice Info
C001 Operating mode -0- -0- Setpoint selection via term. 8 (jumper setting,
see chapter 4.2.8.2)
Control via terminals parameter setting with
8201BB
C005 Configuration -0- -0- Operation with open-loop control via
terminal 8
C014 Control mode -0- -3- Square characteristic Vf
d
2
with constant
V
min
boost
According to the information given in both tables (code setting for unit 1 and 2):
- All other parameters are based on the factorysetting.
