Configuration
8200SHB01997-48
7.5.12 Controller enable RFR
Function Terminal 28 controls the controller enable.
Activation
-
LOW level: Controller inhibited
-
HIGHlevel: Controller enabled
Important
-
During operation with the 8201BB operating module, youcan inhibit the controller with the STP
key and enable it again by pressing the RUN key. Here control terminal 28 and the keypad of the
operating module have the same effect as two separate switches connected in series.
-
For control via a fieldbus module, the controller enable via terminal 28 still has priority.
