series “HVAC”
-41- D/F TRIP set DC injection brake JOG1
-42- D/F TRIP set DC injection brake QSP
-43- D/F TRIP set QSP CW/CCW
-44- D/F PAR DOWN UP
-45- D/F PAR QSP CW/CCW
-46- JOG1 QSP PAR H/Re
-47- JOG1 H/Re CCW/QSP CW/QSP
-48- D/F I-OFF DC injection brake INFL_0
-49- D/F QSP JOG1 INFL_0
-50- D/F I-OFF JOG1 INFL_0
-51- D/F I-OFF PAR DCB
Function Depending on your application you can select a function group under C007. A binarysignal code at
the digital inputs E1 ... E4 activates the functions.
Important Response time of the inputs E1 ... E4:
820X 16 ... 24 ms
821X/822X/824X 2.5 ... 4 ms
Special features
820X The digital inputs E1 ... E4 are without function when using the operating mode ”Control via
LECOM” (C001 = -3-).
821X/822X/824X With the operating mode ”Control via LECOM” (C001=-3-), the functions ”TRIP set” and ”QSP”
remain effective.
Series “HVAC” With the operating mode ”Control via LECOM” (C001=-3-), the functions ”TRIP set” and ”QSP”
remain effective. They can be switched-off with the priority mask (C115).
-
The levels for the input terminals can be inverter under C114.
-
Use the following terminal configuration, if terminal E1 is used for the setpoint or the act. value:
(see chapter 7.5.14.9)
- C007 = -28- ... -45, -48- ... -51-
